TP-LINK TL-SG5428 24-port Gigabit Layer 2 Gigabit Switch w/ 4x SFP Slots
เพิ่มเมื่อ: 2017-03-07 17:09:54.0
แก้ไขล่าสุด: 2019-05-06 17:07:51.0
เบอร์โทรติดต่อ: 062-5193997 , 02-4582949
อีเมลล์: krieng.nt@gmail.comJetStream™ 24-port Pure-Gigabit L2 Managed Switch, 24 10/100/1000Mbps RJ45 ports including 4 Gigabit SFP slots(สินค้ารับประกัน ตลอดอายุการใช้งาน)
TP-LINK TL-SG5428
TL-SG5428 JetStream™ 24-port Pure-Gigabit L2 Managed Switch, 24 10/100/1000Mbps RJ45 ports including 4 Gigabit SFP slots
- LLDP serves to reduce the complexities of the network.
- Link aggregation (LACP) increases aggregated bandwidth, optimising the transport of business critical data.
- IEEE 802.1s Multiple Spanning Tree, provides high link availability in multiple VLAN environments.
- Support IEEE 802.1d/w/s Spanning Tree (STP/RSTP/MSTP).
- IGMP snooping allows the forwarding of multicast packets such as streaming audio and video, without
increasing network broadcast congestion.
- Non-blocking Layer 2 Switching Capacity.
- GVRP (GARP VLAN Registration Protocol) allows automatic learning and dynamic assignment of VLANs.
- Supports 4K active VLAN groups and 4K VLAN IDs.
- Q-in-Q increases the network scalability by providing a hierarchical structure.
- Supports 802.1P, Class of Service (CoS) with 4 priority queues per port.
- Rate limiting confines the traffic flow accurately according to the preset value.
- Supports multiple industry standard user authentication methods such as 802.1x, RADIUS Authentication, Supports.
- 00 IP-MAC-Port-VID Binding entries.
- IP Source Guard prevents IP spoofing attacks such as DoS.
- Port Security enhances the security of all ports.
- L2/L3/L4 Access Control Lists restrict untrusted access to the protected resource.
- Virtual stackable provides high scalability and easy Single-IP-Management.
- Supports Telnet, Cisco like CLI, SNMP v1/v2/v3, RMON and web access.
- Supports SSL and SSH encryptions.
- Port Mirroring enables monitoring selected ingress/egress traffic.
Hardware Specification
- Standards and Protocols
- IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p
- Interface
- 24 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX)
- 4 gigabit SFP Slots
- 1 Console Port
- * The SFP slots support 1000Mbps only.
- Network Media
- 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
- 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m)
- 100BASE-FX: MMF, SMF
- 1000BASE-X: MMF, SMF
- Dimensions (W X D X H)
- 17.32*10.2*1.73 in. (440*260*44 mm)
- Power Supply
- 220~240VAC, 50/60Hz
Performance
- Bandwidth/Backplane 56Gbps
- MAC Address Table 8k
- Packet Forwarding Rate 41.6Mpps
- Jumbo Frame 10240 Bytes
Software Specification
- L2 Switching Features
- IGMP Snooping V1/V2/V3
- 802.3ad LACP (Up to 8 aggregation groups, containing 8 ports per group)
- Spanning Tree STP/RSTP/MSTP
- BPDU Filtering/Guard
- TC/Root Protect
- Loop back detection
- 802.3x Flow Control
- Quality of Service
- Support 802.1p CoS/DSCP priority
- Support 4 priority queues
- Queue scheduling: SP, WRR, SP+WRR
- Port/Flow- based Rate Limiting
- Voice VLAN
- Support
- EEE802.1Q with 4K VLAN groups and 4K VIDs
- Port/ MAC/Protocol-based/Private VLAN
- GARP/GVRP
- Access Control List
- L2`L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID
- Time Range Based
- Security
- IP-MAC-Port-VID Binding
- IEEE 802.1X Port/MAC Based authentication, Radius,Guest VLAN
- DoS Defence
- Dynamic ARP inspection (DAI)
- SSH v1/v2
- SSL v2/v3/TLSv1
- Port Security
- Broadcast/Multicast/Unknown-unicast Storm Control
- Management
-Web-based GUI and CLI management
- SNMP v1/v2c/v3,compatible with public MIBs and TP-LINK private MIBs
- RMON (1, 2, 3, 9 groups)
- DHCP/BOOTP Client, DHCP Snooping, DHCP Option82
- CPU Monitoring
- Port Mirroring
- Time Setting: SNTP
- Integrated NDP/NTDP feature
- Firmware Upgrade: TFTP & Web
- System Diagnose: VCT
- SYSLOG & Public MIBS
General
- Certification
- CE, FCC
- Package Contents
- Switch; Power Cord; Quick Installation Guide; Resource CD; Rackmount Kit; Rubber Feet
- System Requirements
- Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, MAC OS, NetWare, UNIX or Linux.
- Environment Operating
- Temperature: 0C~40C (32F~104F)
- Storage Temperature: -40C~70C (-40F~158F)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
