PLANET VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender

จำนวนครั้งที่เปิดดูสินค้า : 10820 | ความคิดเห็น: 0

PLANET VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender

เพิ่มเมื่อ: 2013-10-16 20:27:06.0

แก้ไขล่าสุด: 2019-05-13 13:47:50.0

เบอร์โทรติดต่อ: 062-5193997 , 02-4582949

อีเมลล์: krieng.nt@gmail.com

รายละเอียด:
VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender (สินค้ารับประกัน 3 ปี)

4200.00 บาท

PLANET VC-202A

VC-202A 1-Port 10/100Base-TX + 1-Port BNC Ethernet over Coaxial Extender

- Defines Asymmetric (Plan 998) and Symmetric for the transmission of upstream and downstream signals

- Cost-effective Profile 17a CO / CPE bridge solution

- One box design, CO / CPE selectable via DIP Switch

- Complies with IEEE 802.3, IEEE 802.3u and IEEE 802.3x standards

- DMT (Discrete Multi-Tone) line coding

- Half Duplex Back-Pressure and IEEE 802.3x Full Duplex Pause Frame Flow-Control

- Supports up to 1,536 bytes packet size, IEEE 802.1Q VLAN tag transparent

- Standalone transceiver for simple bridge modem application

- Advantage of minimum installation time (Simply as Plug-and-Play)

- Selectable target band plan and target SNR margin

- Supports extensive LED indicators for network diagnostics

- Co-work with PLANET MC family Media Chassis (MC-700 / 1500 / 1500R / 1500R48)

- Compact in size, easy installation

Community / Campus Surveillance and Security over IP
To take advantage of digital surveillance system and keep the benefits of coaxial cable, the VC-202A helps the community, campus and enterprises to upgrade analog camera system to IP camera surveillance without using additional new wires. The Extender is a switching architecture with one RJ-45 10/100Mbps Fast Ethernet port and one BNC Ethernet over Coaxial port. Just plug-in the UTP cable of IP camera to Ethernet port and the existing coaxial cable to the BNC connector. It is easy to deploy and extend the distance with signal conversion by transmitting the Ethernet data from the standard coaxial cable. Furthermore, with high transmit data rate, the VC-202A solution supports multiple IP cameras input for sharing in one coaxial cable to reduce the cost of cabling.

MTU / MDU / Hospitality Solution
IPTV, VOD and digital message broadcasting services are the worldwide hot trends, and more and more service providers have upgraded the client side devices from analog system to digital system gradually. The VC-202A will be the best solution because it provides cost-effective and high speed network services by utilizing the existing coaxial cable infrastructure. IP network installation is straightforward. With enough bandwidth, the 100/100Mbps symmetric capability of VC-202A makes many Multi-Media services on local Internet come true, such as VOD (Video on Demand), Voice over IP, Video phone, IPTV, distance education, and so on. It satisfies most of entertainment and communication layer. Meanwhile, this kind of infrastructure also minimizes the burden on the Internet.

Commercial Location Media Network and Electronic Billboards
More and more media network and electronic billboards are built in commercial locations to deliver information over office buildings, shopping centers and stations in the cities. Integrating with Set-Top Box and LCD TV, the VC-202A provides an immediate and interactive broadcasting system over direct Ethernet connection instead of constant content and data exchange by human resource. It can also be integrated with IPTV and Web TV. Through the remote management function, administrators can interrupt the TV program for the News and the commercials. It saves labor and gets better commercial effect.

Hardware Specification
Ports	• 10/100Base-TX: 1 RJ-45, Auto-negotiation and Auto-MDI / MDI-X • Coaxial: 1 BNC, female connector
DIP Switch	4 position DIP switch
Functionality	• CO / CPE mode select • Selectable fast and interleaved mode • Selectable target Band Plan • Selectable target SNR mode
Encoding	•DMT (Discrete Multi-Tone) line coding - ITU-T G.997.1 - ITU-T G.993.1 - ITU-T G.993.2 (Profile 17a Support)
LED Indicators	• One Power • 3 for Coaxial (BNC): - Green, LNK - Green, CO mode - Green, CPE mode • 2 for per RJ-45 10/100Base-TX port - Green, LNK / ACT - Green, Speed
Cabling	• Ethernet : 10Base-T: 2-pair UTP Cat.3, 4 and 5 up to 100m (328ft) • Ethernet : 100Base-TX: 2-pair UTP Cat.5, 5e and 6 up to 100m (328ft) • Coaxial Cable: 50ohm, RG58A / U, RG58C / U, RG58 / U or equivalent; 75ohm, RG-6 (Distance up to 3.0km)
Performance	Asymmetric: 200m ->100/65Mbps 400m ->100/64Mbps 600m ->100/59Mbps 800m ->100/53Mbps 1000m -> 94/44Mbps 1200m -> 84/36Mbps 1400m -> 74/28Mbps 1600m -> 66/19Mbps 1800m -> 60/14Mbps 2000m -> 44/15Mbps 2200m -> 35/12Mbps 2400m -> 32/10Mbps 2600m -> 29/8Mbps 2800m -> 27/6Mbps 3000m -> 25/5Mbps Symmetric： 200m ->99.7/100Mbps 400m ->100/100Mbps 600m -> 86/91Mbps 800m -> 79/80Mbps 1000m -> 69/66Mbps 1200m -> 60/52Mbps 1400m -> 51/41Mbps 1600m -> 45/36Mbps 1800m -> 40/29Mbps 2000m -> 27/26Mbps 2200m -> 23/24Mbps 2400m -> 22/21Mbps 2600m -> 20/18Mbps 2800m -> 18/15Mbps 3000m -> 17/13Mbps
Dimension (W x D x H)	97 x 70 x 26 mm
Weight	0.2 kg
Power Requirement	5V DC 2A
Power Consumption	6.3Watts / 21BTU (maximum)
Standard Conformance
Regulation Compliance	FCC Part 15 Class A, CE
Standards Compliance	IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX IEEE 802.3x Full Duplex Pause Frame Flow-Control ITU-T - G.993.1 - G.997.1 - G.993.2 (Profile 17a Support)
Environment
Operating	Temperature: 0 ~ 50 Degree C Humidity:5~90%, relative humidity (non-condensing)
Storage	Temperature: -10~70 Degree C Humidity:5~90%, relative humidity (non-condensing)
